| Video/Audio Input |
|
| IP video input: |
| |
32-ch |
|
| Two-way audio input: |
| |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
|
| Incoming bandwidth: |
| |
160Mbps |
|
| Outgoing bandwidth: |
| |
80Mbps |
|
| Remote connection: |
| |
128 |
| Video/Audio Output |
|
| HDMI/VGA output: |
| |
1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz |
|
| Recording Resolution: |
| |
6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
| Frame Rate: |
| |
Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: |
|
1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback: |
|
16-ch |
|
| Decoding |
|
| Capability: |
| |
16-ch@4CIF, 12-ch@720P,
6-ch@1080P |
|
| Live view / Playback: |
| |
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Hard Disk |
|
| SATA: |
| |
4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
|
| Capacity: |
| |
Up to 6TB capacity for each HDD |
| External Interface |
|
| Network Interface: |
| |
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
|
| USB Interface: |
| |
Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0 |
|
| Alarm In: |
| |
16-ch |
|
| Alarm Out: |
| |
4-ch |
| POE |
| Supported Standard: |
|
AF and AT |
| Interface: |
|
16 independent 100 Mbps PoE network interfaces |
| Max. Power: |
|
200W |
|
|
|
| General |
|
| Power Supply: |
| |
100~240VAC |
|
| Consumption(without hard disk and POE): |
| |
≤ 20W |
|
| Working Temperature: |
| |
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
|
| Working Humidity: |
| |
10 % ~ 90 % |
|
| Chassis: |
| |
19-inch rack-mounted 1.5U chassis |
|
| Dimensions: |
| |
445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
|
| Weight(without HDD): |
| |
≤ 4 Kg (8.82 lb) |
