| Camera |
|
| Image Sensor: |
| |
1/3" Progressive Scan CMOS |
|
| Signal System: |
| |
PAL/NTSC |
|
| Effective Pixels: |
| |
1920(H)*1080(V) |
|
| Min. Illumination: |
| |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
0.014 Lux @ (F1.4,AGC ON),0 Lux with IR |
|
| Shutter Time: |
| |
1/25(1/30) s to 1/50,000 s |
|
| Lens: |
| |
2.8-12mm @ F1.4
Angle of view: 92° - 32° |
|
| Lens Mount: |
| |
φ14 |
|
|
| Adjustment Range: |
| |
Pan: 0 - 355°, Tilt: 0 - 80°, Rotation: ± 90° |
|
| Day& Night: |
| |
IR cut filter with auto switch |
|
| Video Frame Rate: |
| |
1080p@25fps/1080p@30fps |
|
| Synchronization: |
| |
Internal Synchronization |
|
| Video Output: |
| |
1Vp-p Composite Output (75Ω/BNC) |
|
| S/N Ratio: |
| |
More than 52dB |
|
| Up the Coax: |
| |
Support |
| Menu |
|
| Camera ID: |
| |
On/off (15 characters, position programmable) |
|
| D/N Mode: |
| |
Color/ BW/ EXT |
|
| Auto White Balance: |
| |
ATW/ AWC-SET/ Indoor/ Outdoor/ Manual |
|
| Private Mask: |
| |
On/Off, maximum 8 zones |
|
| Motion Detection: |
| |
On/Off, maximum 4 zones |
|
| BLC: |
| |
On/Off |
|
| AGC: |
| |
Support |
|
| Anti-flicker: |
| |
On/ Off |
|
| Language: |
| |
English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic |
|
| Function: |
| |
Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel
correction, SMART D-ZOOM |
|
| Scene: |
| |
Indoor, Outdoor, Indoor1, LOW-LIGHT |
| General |
|
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 90% or less (non-condensing) |
|
| Power Supply: |
| |
12 V DC ± 10%
(-A series support 24 V AC ± 10%, 12 V DC ± 10%)
|
|
| Power Consumption: |
| |
12 VDC: Max4W
24 VAC: Max5W |
|
| Impact Protection: |
| |
IEC60068-2-75 test, Eh, 20J; EN50102, up to IK10 |
|
| Weather Proof: |
| |
IP66 |
|
| IR Range: |
| |
Up to 40m |
|
| Dimension: |
| |
φ145.3 × 124.2 mm (φ5.72 × 4.89) |
|
| Weight: |
| |
880 g (1.95 lb) |
